The hull of a ship. The hull of a ship is the most important as well as the most noticeable part of the ship. It is the watertight part of any vessel or even boat. The hull is a ships watertight enclosure engineered to provide sufficient protection for the cargo machinery and passenger accommodations.

Its most basic purpose is to safeguard against weather flooding andor structural damage. The hull is the main body of the ship below the main outside deck. The hull consists of an outside covering or skin and an inside framework to which the skin is secured.

The skin and framework are usually made of steel and secured by welding. However there may still be some areas where rivets are used. The ship hull is subjected to static and dynamic hydrostatic pressure on its bottom two sides and under loads due to the weight of the cargo inside the hull seen in Figure 87.

The transverse loads may cause cross-sectional deformation as depicted by the dotted lines and may cause stresses in transverse bulkheads floors side frames and deck beams. The hull of the ship is the part that forms the Vessel This is the outer edge of the ship from the gunwales to the keel and back up above the waterline to the gunwales on the other side. From stem to stern.

It does not include the superstructure rigging masts machinery etc. Just the outer shell of the ship. The hull is one part of the ship that requires extra concern during design and construction.
